QuickSpecs
hp ProLiant ML570
Generation 2 (G2)
DA-11421
World Wide — Version 2 — November 19, 2002
35
Storage
D
R I V E
S
U P P O R T
(continued)
Quantity
Supported
Position
Supported
Controller
External Storage
StorageWorks Enclosure 4300
(supports
Ultra3 drives only)
Up to 20
External
Smart Array 532 Controller
Smart Array 5302/128 Controller
Smart Array 5304/256 Controller
Smart Array 5312 Controller
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
3U Rackmount Kit
5U Rackmount Kit
Up to 3
External
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
3U RM Storage Expander
Up to 3
External
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
StorageWorks Raid Array 4100 Kit
Up to 10
(with optional
StorageWorks Hubs
or Switches)
External
64-Bit/66MHz Fibre Channel Host Adapter
MSA 1000
Please see the MSA
1000 QuickSpecs
below to determine
configuration
requirements
External
Please see the MSA 1000 QuickSpecs (URL below) for the latest list of
supported HBAs
MSA 1000:
http://www5.compaq.com/products/quickspecs/11033_div/11033_div.HTML
(Division/World Wide)
http://www5.compaq.com/products/quickspecs/11033_na/11033_na.HTML
(North America)
Maximum Storage Capacity – (Ultra3 Drive Cage, ML5xx Internal Two Bay Hot Plug Wide Ultra3 SCSI Drive Cage (with Fan) & StorageWorks Enclosure)
Internal
1.019 GB ((12 x 72.8-GB) + (2 x 72.8-GB) Wide Ultra3 SCSI 1
″
Drives)
External
20.384 TB hot plug SCSI storage (20 x (14 x 72.8-GB 1
″
Wide Ultra3 SCSI Drives))
Total
21.403 TB
Maximum Storage Capacity – (External RAID Array 4100 Attached)
Internal
1.019 GB ((12 x 72.8-GB) + (2 x 72.8-GB) Wide Ultra3 SCSI 1
″
Drives)
External
8.736 TB (10 x (12 x 72.8-GB 1
″
Wide Ultra3 SCSI 1
″
Drives)
Total
9.755 TB
Tape Drives
Note: For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the following:
http://www5.compaq.com/products/quickspecs/North_America/10233.html
(North America)
http://www5.compaq.com/products/quickspecs/Division/10233.html
(Division/World Wide)
Note: For an up-to-date listing of the latest O/S Support details for each of the Tape Storage Systems listed below, please see the following:
http://www5.compaq.com/products/quickspecs/North_America/10809.html
(North America)
http://www5.compaq.com/products/quickspecs/Division/10809.html
(Division/World Wide)
Internal AIT 100-GB, Hot Plug
Internal AIT 50-GB, Hot Plug
Internal AIT 35-GB, LVD Hot Plug
Internal 20/40-GB DAT Drive, Hot Plug
Up to 5
2-11
Smart Array 532 Controller
Smart Array 5302/128 Controller
Smart Array 5304/256 Controller
Smart Array 5312 Controller
*Note: The Smart Array 532 does not support the AIT
100-GB Hot Plug Tape Drive.
Internal 20/40-GB DAT DDS-4
Internal 12/24-GB DAT
Up to 2
C, D
Integrated Dual Channel Wide Ultra3 Adapter
Wide-Ultra SCSI-3 Adapter
64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
64-Bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
