HP ProLiant ML570 - Manual (Page 23)

QuickSpecs
hp ProLiant ML570
Generation 2 (G2)
DA-11421 World Wide — Version 2 — November 19, 2002 23
Options
SNMP Serial Port Card
Note: Supports tower and rack UPS XR models ranging from 1000 - 3000VA.
192189-B21 UPS Options
Six Port Card
Note: Supports tower and rack UPS XR models ranging from 1000 - 3000VA.
192185-B21
High to Low Voltage Transformer (250VA)
Note: Supports R6000 UPS series only. 2.5 amps @ 125 Volts max output across two
NEMA 5-15.
388643-B21
Extended Runtime Module, T1000 XR
Note: 2U each, two ERM maximum.
218967-B21
Extended Runtime Module, T1500 XR/T2200 XR
Note: 3U each, one ERM maximum.
218969-B21
Extended Runtime Module, R1500 XR
Note: 2U each, two ERM maximum.
218971-B21
Extended Runtime Module, R3000 XR
Note: 3U each, one ERM maximum.
192188-B21
Extended Runtime Module, R6000
Note: 3U each, two ERM maximum.
347224-B21
Extended Runtime Module, R12000 XR, 4U each, two ERMs maximum 217800-B21
SNMP-EN Adapter
Note: Supports R6000 UPS series only.
347225-B21
Multi-Server UPS Card
Note: Supports R6000 UPS series only.
123508-B21
Scalable UPS Card
Note: Supports R6000 UPS series only.
123509-B21
Compaq Power Distribution Unit-16A (200 to 240V) (WW)
Note: The 16A PDU also connects to the high volt models of the UPS R3000 XR (need
cable P/N 340653-001 for North America) and the UPS R6000 models. Cable
P/N 340653-001 required if connecting to UPS R3000 XR (192186-002 NA-High
Volt model only).
207590-B21 Rack- Mountable PDUs – 1U/0U
(Up to 12 outlets)
Note: 0U mounting brackets shipped with
the unit (separate option kit for 1U
mounting).
Compaq Power Distribution Unit-24A (200 to 240V) (NA, Japan, LA)
Note: This PDU may also be used to connect to the low volt UPS R3000 XR model.
207590-D72
Compaq Power Distribution Unit-32A (200 to 240V) (Int’l) 207590-B31
Compaq Power Distribution Unit-40A (200 to 240V) 207590-B23
Compaq Power Distribution Unit-24A (100 to 127V) (NA, Japan, LA) 207590-D71
1U PDU Mounting Brackets Kit 215852-B21
Note; Please see the following Power Distribution Unit (Zero-U/1U PDU) QuickSpecs for additional options
including cables:
http://www5.compaq.com/products/quickspecs/10838_na/10838_na.HTML (North America)
http://www5.compaq.com/products/quickspecs/10838_div/10838_div.HTML (Division/World Wide)
Compaq Dual Input Power Distribution Unit-24A High Voltage (NA only)
191186-001
Compaq Dual Input Power Distribution Unit-24A High Voltage (Int’l) 191186-B31
Dual Input PDUs – 1U/0U
(Up to 12 outlets)
Note: 1U/0U mounting brackets shipped
with the unit (optimized for 10000
and 9000 series racks)
Note: Please see the following Power Distribution Unit (Zero-U/1U PDU) QuickSpecs for additional options
including cables:
http://www5.compaq.com/products/quickspecs/10838_na/10838_na.HTML (North America)
http://www5.compaq.com/products/quickspecs/10838_div/10838_div.HTML (Division/World Wide)
