QuickSpecs
hp ProLiant ML570
Generation 2 (G2)
DA-11421 World Wide — Version 2 — November 19, 2002 24
Options
Modular PDUs – 1U/0U
(Up to 32 outlets)
Note: 1U/0U mounting brackets shipped
with the unit (optimized for 10000 and
9000 series racks)
Modular Power Distribution Units (mPDU), High Volt Model, 16A (200-240 VAC) (WW)
Note: This model has a detachable input power cord and is adaptable to country specific
requirements. The 16A PDU also connects to the high volt models of the UPS
R3000 XR and R6000 models. Cable P/N 340653-001 required if connecting to
UPS R3000 XR (192186-002 NA -High Volt model only).
252663-B24
Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC)
(NA, Japan)
Note: This model has a detachable input power cord and is adaptable to country
specific requirements. The 16A PDU also connects to the high volt models of the
UPS R3000 XR and R6000 models. Cable P/N 340653-001 required if
connecting to UPS R3000 XR (192186-002 NA -High Volt model only).
252663-D71
Modular Power Distribution Units (mPDU), High Volt Model, 24A (200-240 VAC)
(NA, Japan) 252663-D72
Modular Power Distribution Units (mPDU), High Volt Model, 32A (200-240 VAC) (Int'l) 252663-B31
Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC) (WW)
Note: The 40A model has a hardwired input.
252663-B21
Note: Please see the following Modular Power Distribution Unit (Zero-U/1U Modular PDUs) QuickSpecs for
additional options including cables:
http://www5.compaq.com/products/quickspecs/11041_na/11041_na.HTML (North America)
http://www5.compaq.com/products/quickspecs/11041_div/11041_div.HTML (Division/World Wide)
Rack Builder Compaq Rack Builder for configuration assistance at
http://www.compaq.com/rackbuilder/ .
Rack Conversion Kit ProLiant Tower to Rack Conversion Kit
Note: This Tower to Rack Conversion Kit (PN 253699-B21) supports the ProLiant
ML570 G2 and ML530 G2 servers.
253699-B21
ProLiant Rack to Tower Conversion Kit
Note: This Rack to Tower Conversion Kit (PN 271258-B21) supports the ProLiant
ML570 G2 and ML530 G2 servers.
271258-B21
Third Party Rack Kit ML570 G2 rack model support:
The ML570 G2 Third Party rack kit provides support for any rack, 274739-B21 square
hole or round hole, (including HP Rack System /E and HP Systems), with an adjustment
range from 23 1/2”– 34” deep.
Note: The Third party rack kit is required for round hole racks or for square hole racks
that do not conform to the adjustment range of the standard rail that ships with the
server.
274739-B21
Telco Rack Support ML570 G2 rack model support:
Support for all 2-post Telco racks requires the Third Party Rack 274739-B21 option kit
plus an additional option kit from Rack Solutions. The Rack Solutions brackets can be
purchased at: http://www.racksolutions.com/compaq
274739-B21
Compaq Rack 10842 (42U, 800 mm wide) Rack Cabinet - Pallet
257415-B21 Compaq Rack 10000 Series
(Graphite Metallic)
Compaq Rack 10842 (42U, 800 mm wide) Rack Cabinet - Shock Pallet 257415-B22
Compaq Rack 10647 (47U) – Pallet 245160-B21
Compaq Rack 10647 (47U) – Crated 245160-B23
Compaq Rack 10642 (42U) – Pallet 245161-B21
Compaq Rack 10642 (42U) – Shock Pallet 245161-B22
Compaq Rack 10642 (42U) – Crated 245161-B23
Compaq Rack 10636 (36U) – Pallet 245162-B21
Compaq Rack 10636 (36U) – Shock Pallet 245162-B22
Compaq Rack 10636 (36U) – Crate 245162-B23
Compaq Rack 10622 (22U) – Pallet 245163-B21
Compaq Rack 10622 (22U) – Shock Pallet 245163-B22
Compaq Rack 10622 (22U) – Crated 245163-B23
Note: -B21 (pallet) used to ship empty racks shipped on a truck
-B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels)
-B23 (crated) used for air shipments of empty racks
