Setting Up the HP NetServer E 800
Introduction
This installation guide is a quick reference for HP NetServer E 800 installation.
Skip any steps that do not apply to your installation. Refer to the figures below
for connection and operating information. For more information, refer to the
HP NetServer E 800 User Guide.
Flexible
Disk Drive
CD-ROM Drive
Power ON/OFF/
Sleep Switch
Power ON/
OFF/Sleep LED
SCSI Drive
Activity LED
Optional Back-Up
Tape Drive
Power
Mouse
Keyboard
USB(2)
LAN Serial A
Parallel
Serial B
Video
(SVGA)
Key Lock
External SCSI
(Optional)
Fold-Out
Feet (4)
Unlocked Position
Locked Position
