HP E 800 User Manual
Page 22
Setting Up the HP NetServer E 800
18
6. Connect the fan connector to the respective connector on the system
board.
Processor 1 (CPU 1)
Processor 2
(CPU 2)
CPU 1 Fan
CPU 2 Fan
System
Fan
Power
Connector
CAUTION
Failure to connect the fan connector will cause the processor
to overheat and the NetServer will shut down without any
messages being displayed. If the processor is allowed to
overheat, damage may occur.
