(Optional Secondary) Slots # Width ** Width Number *
4 PCIe Gen2 X8 X16 16 Full length,
full height
slot
5 PCIe Gen2 X4 X8 20 Half length,
half height
slot
6 PCIe Gen2 X4 X8 23 Half length,
half height
slot
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
PCIe/PCI-X Riser
(Optional Primary) Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
1 PCI-X
(133MHz)
64-bit N/A 7 Full length,
Full Height
2 PCI-E Gen2 X8 X16 11 Half Length,
Full Height
3 PCI-E Gen2 X4 X8 15 Half Length,
Full Height
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
PCIe/PCI-X Riser
(Optional Secondary) Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
4 PCI-X
(133MHz)
64-bit Not
applicable
19 Full length,
Full height
slot
5 PCI-E Gen2 X8 X16 23 Half Length,
Half Height
6 PCI-E Gen2 X4 X8 27 Half Length,
Half Height
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
x16 PCIe Riser
(Optional Primary) Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
1 PCIe Gen2 x16 x16 13 Full Length,
Full Height
slot
Supports up
to 225W;
single wide
cards only
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
x16 PCIe Riser
(Optional Secondary) Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
QuickSpecs
HP ProLiant DL380 Generation 6
Standard Features
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009 Page 6
