NOTE: Product conformance to cited product specifications is based on
sample (type) testing, evaluation, or assessment. This product or family
of products is eligible to bear the appropriate compliance logos and
statements.
NOTE: The Listed sound levels apply to standard shipping
configurations. Additional options may result in increased sound levels.
Smart Array P410i
Controller Dimensions (not
including bracket) Low Profile PCIe Form Factor
7.5 in x 9.5 in x 2.25 in (19.05 cm x 24.13 cm x 5.72 cm)
Disk Drive and
Enclosure Interface -
transfer rate 3G SAS (Serial Attached SCSI)
1.5G SATA (Serial ATA)
SAS Connectors 2 internal (Mini-SAS) x8 wide port connectors
Cache Memory Speed DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s
maximum bandwidth.
Server Interface x8 2.5G PCIe 2.0 provides 2GB/s maximum bandwidth
SAS Speed x8 3G SAS provides 2.4GB/s maximum bandwidth
Cache Memory 40-bit 256MB ECC protected cache (72-bit 512MB BBWC module
upgrades available); transportable with battery-backed upgrade
Logical Drives
Supported Up to 32 logical drives
Maximum Logical Drive
Capacity Greater than 2TB
Host Memory
Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support RAID 6, 6+0 (Advanced Data Guarding)
NOTE: The minimum of 256 MB cache, battery kit, and Smart Array
Advanced Pack License Key upgrade is required to enable RAID 6, 6+0
RAID 5, 5+0 (Distributed Data Guarding)
NOTE: The 256 MB & Battery Kit upgrade is required to enable RAID 5,
5+0 support of the Smart Array P410i.
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware Upgradeable Firmware with Recovery ROM feature
QuickSpecs
HP ProLiant DL380 Generation 6
Technical Specifications
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009 Page 49
