HP DX2390 - Manual (Page 9)

Unit Environment and
Operating Conditions General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required
airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer.
Lint, dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating 50° to 95° F (10° to 35° C)
Non-operating -22° to 140° F (-30° to 60° C)
Relative Humidity Operating 10% to 90% (non-condensing at ambient)
Non-operating 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized) Operating 10,000 ft (3048 m)
Non-operating 30,000 ft (9000 m)
NOTE:Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000 m) above
sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be
limited by the type and number of options installed.
System Board Processor Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo, Celeron 4xx or Dual Core
PWM ISL6312 – 3 Phase
Chipset Intel G31 Express
Intel I/O Controller Hub 7 (ICH7)
Super I/O Fintek F71882FG
Front Side Bus Frequency 800/1066/1333 MHz
Memory DDR2 SDRAM
2 x DIMM slots
Clock Generator RTM 876-665
Integrated Graphics Intel Graphics Media Accelerator (GMA)
Audio Realtek ALC662 HD Audio compatible codec with two channel audio 3D
audio
LOM Realtek RTL8101E 10/100 Fast Ethernet controller
Storage Four Serial ATA interfaces
Expansion Slots 1 x PCI 2.3 slot
2 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS SPI EEPROM
QuickSpecs
HP Compaq dx2390 Microtower Business PC
(EMEA, APJ, and Brazil Only)
System Details
DA - 12990 Worldwide QuickSpecs — Version 8 — 4/3/2009 Page 9
