HP DX2390 - Manual (Page 8)

Weight & Dimensions Chassis Dimensions
(H x W x D) 15.16 x 7.28 x 16.38 in. with bezel
(385 x 185 x 416 mm)
14.88 x 6.50 x 16.10 in. without bezel
(378 x 165 x 409 mm)
Packaged Dimensions
(L x W x H) 19.13 x 21.875 x 10.13 in
490 x 556 x 257 mm
System Weight 22.4 lb (10.2 kg)
Shipping Weight 30.8 lb (14.0 kg)
Technology and Features Memory Type PC2-6400 DDR2 SDRAM (800MHz) non-ECC
Up to 4-GB maximum system memory supported
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all
memory may not be available due to system resource requirements. Addressing memory above 4 GB
requires a 64-bit operating system.
Hard Drive Interfaces
Supported Serial ATA
Chassis Front Panel Power button
Power On LED
HDD Activity LED
Cooling Solutions
Supported Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan
Slots Supported Four (4) full-height expansion slots
Front I/O Two (2) USB 2.0 ports
Rear I/O Standard Micro ATX I/O connectors, including four (4) USB 2.0 ports
Drive Bays Two (2) 5-1/4” external
One (1) 3-1/2” external
Two (2) 3-1/2” internal
Internal Speaker N/A
Security Padlock loop
Kensington Lock Support
Support for chassis padlocks and cable lock devices
Optional USB Port Disable at factory (user configurable via BIOS)
Power Supply 250-watt ATX Power Supply – PFC/non-PFC with a 115v/230v line switch
(varies by country/region)
QuickSpecs
HP Compaq dx2390 Microtower Business PC
(EMEA, APJ, and Brazil Only)
System Details
DA - 12990 Worldwide QuickSpecs — Version 8 — 4/3/2009 Page 8
