HP Wireless A+G PCI Dimensions 4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm)
Weight 0.268 lb (65 g)
Controller
system interface Atheros AR5414X chipset
PCI Spec 2.2
Network standard IEEE 802.11a/b/g
Frequency band 5.1500 to 5.8500 GHz
2.4000 to 2.4835 GHz
2.4465 to 2.4835 GHz (Europe, Middle East, Asia and Asia Pacific –
excluding Japan)
2.4000 to 2.4697 GHz (Japan)
Operating Temperature32° to 140° F (0° to 60° C), operating
Storage temperature -4° to 176° F (-20° to 80° C), non-operating
Humidity 10% to 85% non-condensing
Operating voltage 5V ± 5%
Power consumption Tx/Rx peak 560/250mA @ 3.3V (max.)
Output power
(approximately) 15 dBM ±2dB
Receive sensitivity -90dBm at 11 Mbps (typical)
Data transfer rate Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super AG
Mode108-Mbps
Spreading DSSS (Direct Sequence Spread Spectrum)
Security 64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM,
Microsoft PEAP,TKIP, WEP
Antenna External 5dBi antenna
Throughput 108 Mbps (only with Belkin 54G or
above router that supports 108 Mbps
speed) 200 ft (60.96 m) – Indoor
54 Mbps 200 ft (60.96 m) – Indoor
11 Mbps 200 ft (60.96 m) – Indoor
Certifications Wi-Fi certified
Certifications for use by
country North America: United States, Canada
Europe: Austria, Belgium, Cyprus, Denmark, Finland, France, Germany,
Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg, Netherlands,
Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom
Australia, New Zealand
HP Wireless
802.11b/g/n PCIe Dimensions (L x H) 3.3 x 4.7 inches (8.5 x 12 cm)
Weight 0.08 pounds (40 g)
Controller Ralink RT2790
System interface PCIExpress x1
Network standard 802.11 b/g/n
QuickSpecs
HP Compaq dx2390 Microtower Business PC
(EMEA, APJ, and Brazil Only)
Technical Specifications - Communications
DA - 12990 Worldwide QuickSpecs — Version 8 — 4/3/2009 Page 21
