QuickSpecs
HP Compaq dx7300 Business PC
Configurable Components
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 9
Graphics Integrated Intel Graphics Media Accelerator 3000
DVI ADD2 SDVO single head full-height Graphics Adapter (PCIe x16)
ATI RADEON X1300 256MB full-height PCIe Card, DVI w/TV
ATI RADEON X1600XT 256MB, full-height PCIe Card, dual DVI w/TV-out
NVIDIA Quadro NVS 280 64-MB PCI dual head VGA Card
NOTE: *Two NVIDIA Quadro NVS 280 PCI graphics cards can be installed to provide support for
four monitors.
Integrated High Definition audio with Realtek 4-channel ALC262 codec (all ports are stereo)
Microphone and Headphone front ports
Microphone rear port*
Line-out and Line-In rear ports*
Multistreaming capable*
Internal Speaker
Audio
*NOTE: *Rear audio ports are re-taskable as Line-in, Line-out, or Microphone-in. External speakers
must be powered externally. Multistreaming can be enabled in the Realtek control panel to allow
independant audio streams to be sent to/from the front and rear jacks. This allows for different audio
applications to use separate audio ports on the system. For example, the front jacks could be used
with a headset for a communications application while the rear jacks are being used with external
speakers and a multimedia application.
HP PS/2 Standard Keyboard
HP USB BG1650 Keyboard
HP USB Standard Keyboard
Keyboard –
One of the following
HP USB Smartcard Keyboard
HP PS/2 2-Button Scroll Mouse
HP PS/2 2-Button Optical Scroll Mouse
Mouse –
One of the following
HP USB 2-Button Optical Scroll Mouse
HP FireWire / IEEE 1394 PCI Card (full height) Miscellaneous
2nd serial port adapter (full height)
