QuickSpecs
HP Compaq dx7300 Business PC
Technical Specifications
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 15
Dual-State Power Button Power button acts as both an on/off button and suspend-to-sleep button
Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table
Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
• System/Emergency ROM • Flash ROM • CMOS Battery Holder for easy
Replacement
• Flash Recovery with Video
Configuration Record SW • 5 Aux Power LED on System
PCA • Processor ZIF Socket for easy Upgrade
• Over-Temp Warning on Screen
(Requires IM Agents) • Clear Password Jumper • DIMM Connectors for easy Upgrade
• HP Backup and Recovery
Manager • Clear CMOS Button • NIC LEDs (integrated) (Green & Amber)
Serviceability Features of Chassis
• Dual Color Power and HD LED
– To Indicate Normal
Operations and Fault
Conditions • Color coordinated cables and
connectors • Tool-less Hood Removal
• Front power switch • System memory can be
upgraded without removing the
system board or any internal
components • Tool-less Hard Drive, CD & Diskette
Removal
• Green Pull Tabs, and Quick
Release Latches for easy
Identification • Tool-less System Board Removal
Feature Description
ASF 2.0 support (Alert Standard
Format) Industry-standard specification for network alerting in operating system-absent
environments
Drive Lock* Implementation of the industry standard ATA Security feature set. When enabled, it
prevents software access to user data on the drive until one or two user-defined
