HP dx7300 - Manual (Page 29)

QuickSpecs
HP Compaq dx7300 Business PC
Technical Specifications - Input/Output Devices
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 29
Weight 2 lb (0.9 kg) minimum
Operating voltage + 5VDC ± 5%
Power consumption 50-mA maximum (with three LEDs ON)
System interface PS/2 6-pin mini din connector
ESD CE level 4, 15-kV air discharge
EMI – RFI Conforms to FCC rules for a Class B computing
device
Electrical
Microsoft PC 99 – 2001 Functionally compliant
Languages 38 available
Keycaps Low-profile design
Switch actuation 55-g nominal peak force with tactile feedback
Switch life 20 million keystrokes (using Hasco modified
tester)
Switch type Contamination-resistant switch membrane
Key-leveling mechanisms For all double-wide and greater-length keys
Cable length 6 ft (1.8 m)
Microsoft PC 99 – 2001 Mechanically compliant
Mechanical
Acoustics 43-dBA maximum sound pressure level
Operating temperature 50° to 122° F (10° to 50° C)
Non-operating
temperature -22° to 140° F (-30° to 60° C)
Operating humidity 10% to 90% (non-condensing at ambient)
Non-operating humidity 20% to 80% (non-condensing at ambient)
Operating shock 40 g, six surfaces
Non-operating shock 80 g, six surfaces
Operating vibration 2-g peak acceleration
Non-operating vibration 4-g peak acceleration
Drop (out of box) 26 in (66 cm) on carpet, six-drop sequence
Environmental
Drop (in box) 42 in (107 cm) on concrete, 16-drop
sequence
Operating system support Microsoft Windows 2000 and Windows XP
Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
Ergonomic compliance ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents Keyboard, keyboard software media, installation guide, warranty card,
safety and comfort guide
Keys 104, 105, 106, 107, 109 layout (depending
upon country)
Form factor USB basic Smart Card keyboard
Colors Carbonite/Silver
HP USB Smartcard
Keyboard Physical
characteristics
Dimensions (H x W x D) 18.2 x 6.3 x 1.3 in (46.3 x 16.1 x 3.3 cm)
