Hunter Fan WHISPERWIND2000TM User Manual
Page 24
24
41277-01 05/98
®
Hunter Fan Company
2500 Frisco Avenue
Memphis, TN 38114
PROBLEM
PROBABLE CAUSE
SOLUTION
Excessive wobbling.
Note: When switching from medium
to low speed, you may notice some fan
wobble. When the fan stabilizes at low
speed, wobble will disappear.
1. Unbalanced blades.
2. Loose blades, Speed Ring™, or
blade medallions.
3. Fan not secure on hanger assem-
bly.
4. Fan hanger ball not seated in
canopy tabs.
1. Use balancing kit included with fan.
2. Tighten all screws.
3. Turn power off, support fan very
carefully, loosen canopy and hang
correctly.
4. Turn power off, support the fan
very carefully, and check that the
hanger ball is properly seated.
If you have tried these troubleshooting solutions and still have trouble,
call 901/745-9222 or visit our Web site at http://www.hunterfan.com.
®
