14
41277-01 05/98
®
Figure 6a - Attaching Fan Blade to Speed Ring™ Using Decorative Medallion
(Speed Ring™ Positioned Upside Down)
STEP 6 - ATTACHING BLADE ASSEMBLY
Speed Ring™
(Positioned
Upside Down)
Fan Blade
Decorative
Medallion
Screw Hunter’s Speed Ring™ (patent pend-
ing) system makes installation easier
than ever by allowing you to put to-
gether the entire blade assembly on
your table or workbench, and then
attach it to the fan in just a few,
simple steps. This process eliminates
the need to attach the blades one-
by-one to an already hanging fan.
ATTACHING FAN BLADES TO
SPEED RING™
1. Position the blade, medallion, and
Speed Ring™ and insert three #8-
32 x 1/2” oval-head Phillips
screws as shown in Figure 6a.
(Hunter Fans use several types of
decorative medallions.)
Note: Some blades are reversible,
with two different finishes. Make
sure you have selected the pre-
ferred finish before proceeding.
2. Tighten the screws.
3. Repeat for all blades.
