Double 15” Console w/ Mounting & V-Mux
Control Panel Bracket
• Total 30” Enclosed Console w/ V-Mux
Control Panel Bracket Top Mounted
• Includes Vehicle Mounting Brackets, up to
four pairs of (EB) Equipment Brackets, and
up to four (FP) Filler Plates - 30” Maximum
• Maximum equipment mounting area is 30”
(double 15”)
C-D2300-_ _ _*
Double 23” Console with Mounting
• Total 46” Enclosed Console
• Includes Vehicle Mounting Brackets, up to
eight pairs of (EB) Equipment Brackets, and
up to eight (FP) Filler Plates - 46” Maximum
• Maximum equipment mounting area is 46”
(double 23”)
OEM Double Consoles Designed to fit Freightliner, International, and Sterling Commercial Cabs (C-D Series)
C-D1510-_ _ _*
*Specify vehicle: F L 1 = ‘04-06 Freightliner Model M-2 , S T 1 = ‘04-06 Sterling Model New Advanced Acterra
I N 1 = ‘04-06 International DuraStar models 4100, 4300, and 4400 and WorkStart models 7300, 7400, 7500, 7600, and 7700
Consoles are 17.8” Wide X 23” Long, 32 lbs.
Light and Medium Truck Consoles
C-2410 C-AB-825-H
Vehicle Specific Consoles
2008 F-250 Pick-Up
C-VS-1200-F250-1
2007-2008 Expedition
C-VS-1200-EXPD-1
2006-2008 Explorer
C-VS-1600-EXPL
2007 Tahoe/Yukon/Suburban
C-VS-1000-TAH
Manufactured by:
C-D_NPR_3-08 rev 6-8
Call Today for Quick Delivery 1-800-524-9900 or visit www.havis.com
New Product Release!
Enclosed Series Console
Light and medium truck consoles (SUV & full
size only)
24” long enclosed 10” high console
Vehicle mounting brackets are included and
are vehicle specific.
Includes filler plates (FP) and/or equipment
brackets (EB) to completely enclose mounting
area less internal mount options
•
•
•
•
25° Angled Mounting Adapter for C-Series Consoles
Offers two different mounting planes when mounted on
Consolidator Consoles (25° angled and 0° horizontal)
9.5” mounting space, 8” total mounting space, 25°
angled console adapter.
Mounts to C-Series and utilizes 9.5” mounting space of
console
4.675” high x 9” wide x 9.5” length
Filler plates (FP) and/or equipment brackets (EB) sold
separately
•
•
•
•
•
Truck Consoles
