RotoFlex™ II Pump (RTX 1250)
311772G 11
Reassemble
1. Bend hose (16) so colored dots on hose fittings face
each other.
2. Slide new pump hose (16) in from side access
panel. Move pump rollers by hand until or flip power
switch to rotate rollers until they are positioned cor-
rectly with pump hose.
3. Replace hose bracket (25) to lock pump hose into
place.
4. Tighten hose bracket knob (42).
5. Flip side access panel (13) down and tighten knob
(42).
6. Replace and tighten screw (70) from side access
panel.
7. Break in new pump by adding 1 cup of water to
pump and running dry for 3 minutes.
ti9331a
ti8868a
ti9288a
25
42
ti8945a
42
ti8938a
70
ti8874a
