22 P/N 214326 8/98
SAND
450 LBS.
(204 KG)
16.
Place unit to desired location. Tip forward as
shown to fill tank with sand (450 lb. (204 kg))
Then snap end cap in place. Upright unit.
Carefully upright assembly and adjust and level
rim height to 10 feet (3.05 m).
Tighten hardware from Step 12.
17.
SAND FILL ONLY!
FAILURE TO FOLLOW
DIRECTIONS COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING
10 feet
(3.05 m)
IMPORTANT! MAKE SURE NET IS HELD
BY ALL THREE HOOKS ON THE NET CLIP.
NOTE: Stretching net up then pulling side to side will help snap
net under center hook.
Install net (25).
15. INSIDE VIEW
25
17
TWO PERSON MINIMUM
REQUIRED FOR THIS
PROCEDURE.
NOT FOLLOWING
RECOMMENDATION MAY
RESULT IN BODILY INJURY.
WARNING
• Vue intérieure
• Vista interior
• Innenansicht
• Vista dall’interno
• Binnenaanzicht
REGULATION RIM HEIGHT
IS 10 FEET (3.05 m).
