Others Functions (Continued)
VGA input adjustment
VGA input adjustment
1. Press the TV/AV button to
select the RGB input mode .
3.Press the CH+/- buttons to move
the indicator to the desired options,
then press the VOL+/- buttons to
adjust the effect of the screen .
Setting the PC software
1.First, click on Settings on the Windows start
menu and click on "Control Panel".
2.Double click on the Display icon.
3.Click on the Settings tab on the display
dialog-box.
4.Adjust the resolution to 640X480 pixels
5.Click the Advanced button and click the Monitor
tab on the dialog-box. Set the vertical-frequency
to 60Hz and then click the OK button.
6. Connect the PC to the TV set by the VGA terminal.
HPOS 0
HSIZE 0
VPOS 0
VSIZE 0
TCC 0
PCC 0
