Connecting to the network – HP 3C905B-TX User Manual
Page 12
HP 10/100 3Com 3C905B-TX Network Interface Card Installation Guide
Connecting to the Network
8 English
Connecting to the Network
Connect the network cable to the RJ-45 UTP (Unshielded Twisted
Pair) LAN connector. The LAN card supports both 10 Mbits/s and 100
Mbits/s operation.
Remote Wake Up
The network interface card is able to wake the PC from a sleep state if
it receives a special sequence (known as a Magic Packet
TM
) from the
network.
RJ-45 UTP
Connector
3com.bk : 3com-us.fb4 Page 8 Thursday, June 18, 1998 4:17 PM
