✁ ✂ ✄ ☎ ✆ ✄ ✝ ✝ ✁ ✂ ✄ ☎ ✆ ✄ ✝ ✝ ✁ ✂ ✄ ☎ ✆ ✄ ✝ ✝ ✁ ✂ ✄ ☎ ✆ ✄ ✝ ✝ Control Keypad 69(96)
7
T6.8.2.4
Operating hours trip
counter
hh:mm: ss
P6.8.2.5
Clear operating time
counter
0 = No action
1 = Clear T6.8.2.3, T6.8.2.4
S6.8.3 Software info
I6.8.3.1 Software package
Scroll information with menu
button right
I6.8.3.2 System SW version
I6.8.3.3 Firmware interface
I6.8.3.4 System load %
S6.8.4 Application info
S6.8.4.1 Application
A6.8.4.1.1 Application id
A6.8.4.1.2 Application version
A6.8.4.1.3 Firmware interface
S6.8.5 Hardware info
I6.8.5.2 Unit voltage V
I6.8.5.3 Brake chopper 0 =Not present, 1=Present
S6.8.6 Options
S6.8.6.1 Slot E OPT-
Note! the submenus are not
showing if no option board is
installed
I6.8.6.1.1 Slot E Status 1 5
1 =Connection lost
2 =Initializing
3 =Run
5 =Fault
I6.8.6.1.2 Slot E Program version
S6.8.6.2 Slot D OPT-
Note! the submenus are not
showing if no option board is
installed
I6.8.6.2.1 Slot D Status 1 5
1 =Connection lost
2 =Initializing
3 =Run
5 =Fault
I6.8.6.2.2 Slot D Program version
S6.9 AI mode
P6.9.1 AIA1 mode 0 1 0
0 =Voltage input
1 =Current input
(Types MF4 – MF6)
P6.9.2 AIA2 mode 0 1 1
0 =Voltage input
1 =Current input
S6.10 Fieldbus parameters
I6.10.1 Communication status
P6.10.2 Fieldbus protocol 1 1 1
0 =Not used
1 =Modbus protocol
P6.10.3 Slave address 1 255 1 Addresses 1 – 255
P6.10.4 Baud rate 0 8 5
0 =300 baud
1 =600 baud
2 =1200 baud
3 =2400 baud
4 =4800 baud
5 =9600 baud
6 =19200 baud
7 =38400 baud
8 =57600 baud
P6.10.5 Stop bits 0 1 0 0 =1 1=2
P6.10.6 Parity type 0 2 0 0 =None 1=Odd 2=Even
P6.10.7
Communication
timeout
0 300 s 0
0 =Not used1=1 second
2 =2 seconds, etc
Table 7-5. System menu functions
