36(96)

Cabling and connections

Honeywell

Figure 6-8. NXL Compact, MF3

Figure 6-9. Cable installation in NXL Compact, MF3

Control
cable

Motor
cable

Mains
cable

Earth terminal

Brake resistor
terminals

BR+

BR-

NOTE! NXL Compact (MF2-3): It is advisable to connect the cables to the
terminals and earthing plate first and then attach the terminals and earthing
plate to the unit.
