Control Keypad
59(96)
7
Code
Signal name
Unit
ID
Description
V1.1
Output frequency
Hz
1
Frequency to the motor
V1.2
Frequency reference
Hz
25
V1.3
Motor speed
rpm
2
Calculated motor speed
V1.4
Motor current
A
3
Measured motor current
V1.5
Motor torque
%
4
Calculated actual torque/nominal torque of the motor
V1.6
Motor power
%
5
Calculated actual power/nominal power of the motor
V1.7
Motor voltage
V
6
Calculated motor voltage
V1.8
DC-link voltage
V
7
Measured DC-link voltage
V1.9
Unit temperature
ºC
8
Heat sink temperature
V1.10
Analogue input 1
13
AI1
V1.11
Analogue input 2
14
AI2
V1.12
Analogue output
current
mA
26
AO1
V1.13
Analogue output
current 1, expander
board
mA
31
V1.14
Analogue output
current 2, expander
board
mA
32
V1.15
DIN1, DIN2, DIN3
15
Digital input statuses
V1.16
DIE1, DIE2, DIE3
33
I/O expander board: Digital input statuses
V1.17
RO1
34
Relay output 1 status
V1.18
ROE1, ROE2, ROE3
35
I/O exp. board: Relay output statuses
V1.19
DOE 1
36
I/O exp. board: Digital output 1 status
V1.20
PID Reference
%
20
In percent of the maximum process reference
V1.21
PID Actual value
%
21
In percent of the maximum actual value
V1.22
PID Error value
%
22
In percent of the maximum error value
V1.23
PID Output
%
23
In percent of the maximum output value
V1.24
Autochange outputs
1,2,3
30
Used only in Pump and Fan Cascade control
V1.25
Mode
66
Shows the current drive configuration mode selected
with start-up wizard:
0 = No mode selected (Default)
1 = Standard
2 = Fan
3 = Pump
4 = High performance
Table 7-2. Monitored signals
