Page 28
28(96)
Cabling and connections
Honeywell
Honeywell
Honeywell
Honeywell
6
6.
CABLING AND CONNECTIONS
6.1
Power connections
Figure 6-1. Power connections, MF2
Figure 6-2. Power connections, NXL Compact MF3 (1~/3~)
Figure 6-3. Power connections, NXL HVAC (MF4-MF6)
nxlk10.fh8
L1 L2
U/T1 V/T2 W/T3
L1 L2 L3
U/T1 V/T2 W/T3
1 ~
3 ~
nxlk11.fh8
L1 L2 L3
U/T1 V/T2 W/T3 BR+ BR-
1~
3~
nxlk58.fh8
L1 L2 L3
B- B+ R-
U/T1 V/T2 W/T3
