Storage Controller
Non-Hot Plug SATA
Models
HP Embedded SATA RAID Controller (integrated into the south-bridge)
supporting SW RAID 0,1,10
NOTE: Transfer rate: up to 3 Gb/s SATA
HP Smart Array B110i SATA RAID
NOTE: To enable RAID for embedded SATA controller, use EZ set-up CD to
download driver, hpahcisr.sys, is part of the 8.20 PSP, Smart Start, EZSetup
CD. For more information on SW Smart Array, go to:
Hot Plug SATA/SAS
Models
HP Smart Array P410 Controller (RAID 0/1/1+0)
HP Smart Array P410 Controller 256 BBWC (RAID/0/1/1+0/5/5+0)
NOTE: Transfer rate: up to 3 Gb/s SATA, up to 3 Gb/s SAS.
NOTE: A diskette drive or virtual FDD using LO100 Advanced Pack is needed to install storage controller
drivers during a Windows operating system installation from a CD.
NOTE: Addition of the battery backed cache upgrade enables BBWC, RAID 5, 5+0, array expansion,
logical drive extension, RAID migration, and stripe size migration.
NOTE: RAID 6 functionality requires the addition of Smart Array Advanced Pack (P/N: 516471-B21).
NOTE: The addition of a Smart Array hardware based storage controller to a Non-Hot Plug SATA Model
is only supported for external storage.
Storage
Diskette Drives
Via USB only
Optical Drives
Optional SATA 9.5mm DVD-ROM Optical Drive
Optional SATA 9.5mm DVD RW Optical Drive
Drive Bays
Up to 4 Non-hot plug SATA 3.5" drives
Up to 4 Hot plug SAS/SATA 3.5" drives
Maximum Internal Storage
Non-Hot Plug SATA
3.0TB
4 x 750GB
Hot Plug SATA
4.0TB
4 x 1TB
Hot Plug SAS
4.0TB
4 x 1TB
Interfaces
Parallel
None
Network RJ-45(Ethernet)
2 10/100/1000 NIC ports (plus 1 optional dedicated port for the HP
ProLiant Lights Out 100i Remote Management)
Serial
1
Pointing Device (Mouse)
0 (via USB only)
Graphics
1
Keyboard
0 (via USB only)
USB
5 (two front, one internal, two rear)
NOTE: In order to connect a USB device internally, the internal USB Cable
G6 Kit must be used (536769-B21)
NOTE: Please see the following URL for additional information regarding USB
support:
