Quickspecs – HP DL160 User Manual
Page 45
HP 460W Power Supply
Part Number - AC 460W PSU 532092-B21 Option Kit
Input Voltage Range (Vrms)
100 to 240
Frequency Range (Nominal) (Hz)
50/60
Nominal Input Voltage (Vrms)
100
120
200
208
220
230
240
Maximum Rated Output Wattage
460
460
460
460
460
460
460
Nominal Input Current (A rms)
5.5
4.5
2.6
2.5
2.4
2.3
2.2
Max Rated Input Wattage Rating
(Watts)
526
520
505
505
503
503
503
Max. Rated VA (Volt-Amp)
548
542
527
527
524
524
524
Efficiency (%) at Max. Rated Output
Wattage
87.5
88.5
91
91
91.5
91.5
91.5
Power Factor
0.97
0.97
0.97
0.97
0.97
0.97
0.97
Leakage Current (mA)
0.42
0.50
0.83
0.87
0.92
0.96
1.00
Max. Inrush Current (A peak)
30
30
30
30
30
30
30
Max. Inrush Current duration (mS)
20
20
20
20
20
20
20
Maximum British Thermal Unit
Rating (BTU-Hr)
1794
1773
1725
1725
1715
1715
1715
HP 400W Power Supply
Part Number - AC 400W PSU 532092-B21 Option Kit
Input Voltage Range (Vrms)
100 to 240
Frequency Range (Nominal) (Hz)
50/60
Nominal Input Voltage (Vrms)
100
120
200
208
220
230
240
Maximum Rated Output Wattage
320
320
360
360
360
360
360
Nominal Input Current (A rms)
4.15
3.41
2.23
2.16
2.03
1.94
1.86
Max Rated Input Wattage Rating
(Watts)
412
406
445
445
444
443
443
Max. Rated VA (Volt-Amp)
413
407
447
447
446
446
445
Efficiency (%) at Max. Rated Output
Wattage
77.4
78.5
80.5
80.6
80.7
80.8
81.0
Power Factor
0.99
0.99
0.99
0.99
0.99
0.99
0.99
Leakage Current (mA)
0.75
0.75
0.85
0.90
0.95
0.95
1.00
Max. Inrush Current (A peak)
35
35
35
35
35
35
35
Max. Inrush Current duration (mS)
20
20
20
20
20
20
20
Maximum British Thermal Unit
Rating (BTU-Hr)
1354
1334
1462
1462
1459
1456
1456
NOTE:
To review typical system power ratings use the Active Answers Power Advisor which is available via the online tool located at URL:
QuickSpecs
HP ProLiant DL160 Generation 6
Power Specifications
DA - 13247 Worldwide QuickSpecs — Version 11 — 11.16.2009
Page 45
