Non-Hot Plug SATA Hard
Drives 160-GB 7.2K
458947-B21 Capacity 160,041 MB
Height 1.028 in (2.61 cm)
Width 4.0 in (10.16 cm)
Depth 5.787 in (147.0 mm)
Interface SATA ATA
Transfer Rate Synchronous
(Maximum) 1.5Gb/s
Seek Time (typical reads,
including settling) Single Track 0.9 ms
Average 9.0 ms
Full-Stroke 17.8 ms
Rotational Speed 7,200 rpm
Physical Configuration Bytes/Sector 512
Logical Blocks 312,581,808
Operating Temperature41° to 131° F (5° to 55° C)
NC362i Integrated Dual
Port Gigabit Server
Adapter Network Interface Integrated 10/100/1000BASE-T Transceiver
Combines a triple-speed IEEE 802.3TM - Compliant Media Access
Controller (MAC) with a triple-speed Ethernet transceiver.
Data Transfer Method Compliant to x1 PCIe Specification
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
1000Base-TX (Half and
Full-Duplex) 2000Mb/s
Connector RJ-45 connector
Cable Support Performs all the physical layer functions for 10BASE-T, 100BASE-T, and
1000BASE-T Ethemet on standard Category 5 UTP
QuickSpecs
HP ProLiant DL160 Generation 6
Technical Specifications
DA - 13247 Worldwide QuickSpecs — Version 11 — 11.16.2009 Page 49
