Appendixes
Aspect Specifications Yes: Available / --: Not Available
Input Signal
Aspect
Auto 4:3 16:9 Full Zoom1 Zoom2
AIR / CABLE Air / Cable Yes Yes Yes -- Yes Yes
HDMI 1 HDMI / DVI
1080p, 1080i, 720p, 480p, 480i Yes Yes Yes Yes Yes Yes
640x480, 800x600, 1024x768,
1280x720, 1360x768
Yes -- -- Yes -- --
HDMI 2 HDMI
1080p, 1080i, 720p, 480p, 480i Yes Yes Yes Yes Yes Yes
HDMI 3 HDMI 1080p, 1080i, 720p, 480p, 480i Yes Yes Yes Yes Yes Yes
HDMI 4 HDMI 1080p, 1080i, 720p, 480p, 480i Yes Yes Yes Yes Yes Yes
COMPONENT 1 YP b P r Yes Yes Yes -- Yes Yes
COMPONENT 2 YP b P r Yes Yes Yes -- Yes Yes
AV 1 Video / S-Video -- Yes Yes -- Yes Yes
AV 2 Video / S-Video (Only for L42A404) -- Yes Yes -- Yes Yes
RGB Analog RGB Yes -- -- Yes -- --
Appendix B: RGB Format for L32A404
Resolution Frequency(Hz)
640x480 60, 72, 75
720x400 70
800x600 56, 60, 72, 75
1024x768 60, 70, 75
1280x720 60
1280x768 60
1360x768 60
Appendix C: RGB Format for L42A404
Resolution Frequency(Hz) Resolution Frequency(Hz)
640x480 60, 72, 75 1280x1024 60
720x400 70 1440x900 60
800x600 56, 60, 72, 75 1680x1050 60
1024x768 60, 70, 75 1920x1080 60
1280x720 60
1280x768 60
1360x768 60
NOTE The type of video board or connecting cable may not allow for correct displays adjustment of H-Position,
V-Position, Clock and Phase.
Appendix A: Picture Format for Each Input Source
