September 1, 2008 Page 49 Quadra-Fire · Castile Gas Stove · 7023-111E
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D.
Service Parts List
(cont’d.)
R
CASTILE GAS
Beginning Manufacturing Date: 5-19-05
Ending Manufacturing Date:
Item
#
Part Description
Alphabetical Order
SKU
Gasket, Flue Collar 455-0660
Gasket, Glass 10 ft. 844-3010
8 Glass Assembly 7010-017
9 Glass Retainer 7010-121
35 Grille, Rear Vent RV-CG-MBK
36 Grille, Top Vent 455-0370BK
33 Igniter, Piezo 230-0612
30 Knob, Rheostat 100-512
18 Latch, Draw 229-0640
15 Log Set LOGS-T1
46 Log Support, Rear 7010-134
6 Magnet Bracket 7023-108
3 Magnet, Round 7000-140
ON/OFF Valve 15697A
Orifice, LP (.063) 17236
Orifice, NG (.106) 19837
48 Pilot Assembly, NG 230-1781
47 Pilot Bracket 7010-135
Relief Door Assembly 7010-003
26 Set Collar, 1/4 in. 229-0750
22 Side, Mill 413-0040BK
Snap Disc Bracket 7009-108
28 Switch Plate 7023-105
32 Switch, Rocker, ON/OFF 230-0730
37 Top, Mill 7021-101
24 Valve, Gas, LP 842-0230
24 Valve, Gas, NG 842-0240
Wire Harness 7010-156
