Reference Materials
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For clearances refer to Section 3.
Figure 12.1 Appliance Dimensions
G
A
B
C
H
I
D
E
F
Location
Inches
Millimeters
Location
Inches
Millimeters
A
23-5/8
600
F
23-5/8
600
B
28-1/2
724
G
20-1/2
521
C
23-5/8
600
H
17-7/8
454
D
8-1/4
210
I
16-1/4
413
E
19-5/8
498
