12 Installing the 3COM EtherLink III 3C509B ISA 10BT Network Adapter

Microsoft Windows for Workgroups 3.11

12 Installing the 3COM EtherLink III 3C509B ISA 10BT
Network Adapter

Microsoft Windows for
Workgroups 3.11

Connecting to a
Windows NT 4.0 Server

Requirements

HP Vectra with MS-DOS and MS-Windows for Workgroups 3.11.

3COM EtherLink III 3C509B-TP ISA 10BT network adapter and driver
disk version 6.0.

Driver File: ELNK3.386, version 1.05.

Microsoft Windows for Workgroups 3.11 media.

Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink
IPX/SPX Compatible Transport and NWLink NetBIOS network protocols.

Device Configuration

Procedure

1 With the HP Vectra turned off, install the 3COM 3C509B network adapter

into an ISA slot.

2 Connect network cable media to the 3COM 3C509B network adapter.

3 Power on the system and boot to MS-DOS.

4 Insert the 3COM 3C509 driver disk and execute “3C5X9CFG.EXE”.

5 Select “CONFIGURE NIC” and verify the resource settings listed above

under the heading “Device Configuration”.

6 If changes are required, save those changes and exit.

7 Remove the 3COM 3C509B driver disk and restart the system.

8 After Windows loads, open the “NETWORK” Program Group, and double-

click on “Network Setup”.

9 Click on the “Networks” button in the “Network Setup” dialog box.

Device Configuration

Vectra Vli8

Vectra VEi7

Vectra VEi8

Interrupt

05

05

05

I/O Address

300

300

300
