Heat & Glo • Bravo • 704-902 Rev. F • 10/08 52
13 in.
(330 mm)
15 in.
(381 mm)
8-1/8 in.
(206 mm)
DVP-HRC, DVP-HRC-SS
NOT APPROVED FOR ALL UNITS.
10-7/8 in.
276 mm
10-1/2 in.
267 mm
3°
87°
Effective Length
5-3/4 to 8-3/8 in.
146 to 213 mm
5-1/2 in.
140 mm 8-3/8 in.
213 mm
DVP-HRC-ZC, DVP-HRC-ZC-SS
NOT APPROVED FOR ALL UNITS.
B. Vent Components Diagrams (continued)
Figure 16. 5 DVP Vent Components
