Heat & Glo • Bravo • 704-902 Rev. F • 10/08 17
Figure 5.8
2. Top Vent - Vertical Termination - (continued)
Three Elbows
IN S TA LL E D
H O R IZO N TA L LY
Note: The first elbow used
MUST always be DVP90ST.
V
1
H
1
+ H
2
V
2
3 ft. 0.9 m 2 ft. 0.6 m *
4 ft. 1.2 m 4 ft. 1.2 m *
5 ft. 1.5 m 6 ft. 1.8 m *
12 ft 3.7 m 20 ft. 6.1 m *
H
1
+ H
2
= 20 ft (6.1 m) Maximum
*No specifi c restrictions on this value EXCEPT
V
1
+ V
2
+ H
1
+ H
2
= 40 ft (12.2 m) Maximum
Note: V
1
MUST be a minimum
of 3 feet unless using the TAOS
surround. For TAOS surround, V
1
minimum MUST be 30 in.
