Hitachi DV-W1U User Manual
Page 21
4 - 4
P-NO DESCRIPTION
SYMBOL
NO
P-NO DESCRIPTION
SYMBOL
NO
TRANSFORMER
T1301
BS10231U
COIL
COILS
L1301
BA10337R
COIL 100UH
L1362
BA10334R
COIL 10UH
L1701
BA10337R
COIL 100UH
CRYSTAL
X1701
BP10891R
CRYSTAL
MISCELLANEOUS
BL1303
0103831
CHIP RESISTOR 100 OHM+-5% 0.1W
BL1307
BM00155R
FILTER
BL1309
BM00155R
FILTER
BL1310
BM00155R
FILTER
BL1311
BM00155R
FILTER
BL1312
BM00155R
FILTER
BL1313
BM00155R
FILTER
BL1314
BM00155R
FILTER
CN1201 EF11761
CONNECTOR
CN1301 1880387
FLEXIBLE CABLE
CN1302 1880386
FLEXIBLE CABLE
CN1303 1880359
FLEXIBLE CABLE
CN1304 EF11751
CONNECTOR
CN1362 EF11771
CONNECTOR
CN1500 EF11262
CONNECTOR
CN1703 1880383
FLEXIBLE CABLE
CN1901 EZ10512
CONNECTOR
CN1905 EK10906
CONNECTOR
CN1906 EF11781
CONNECTOR
CN1907 1880363
FLEXIBLE CABLE
J1301
EQ10351
JACK
J1304
ER10351
JACK
J1305
ER10352
CORD,AC
J1306
EQ10361
JACK
J1761
ER10321
JACK
PG1301 ED10954
CONNECTOR
PG1302 ED10945
CONNECTOR
PG1303 ED10943
CONNECTOR
PG1304 5666436
PLUG
PG1701 5843852
CONNECTOR
PG1702 5843853
CONNECTOR
PG1704 ED12641
CONNECTOR
PG1705 ED12642
CONNECTOR
PG1901 5666574
PLUG
PG1902 5666575
MINI PLUG
PG1903 ED10936
CONNECTOR
PG1904 ED10945
CONNECTOR
PG1905 ED10937
PLUG
PG1906 ED12621
CONNECTOR
PG1907 ED10943
CONNECTOR
R3530
0103864
CHIP RESISTOR 56KOHM+-5% 0.1W
R3531
0103848
CHIP RESISTOR 2.7KOHM+-5% 0.1W
R3532
0103864
CHIP RESISTOR 56KOHM+-5% 0.1W
R3537
0103852
CHIP RESISTOR 5.6KOHM+-5% 0.1W
RV1761 AY10231
VARIABLE RESISTOR
SEMI-CONDUCTORS
D1302
5337411
DIODE HSM2838C
D1303
5337411
DIODE HSM2838C
D1304
5337411
DIODE HSM2838C
D1901
5337101
DIODE MA110
D3301
5337411
DIODE HSM2838C
D3302
5337411
DIODE HSM2838C
IC1301
CK31781R
IC TC74HCT04AF(EL)
IC1302
DT10371
IC JFJ1000
IC1303
DT10381
IC JFJ2000
IC1304
CK23621R
IC TC7WHU04FU
IC1305
CK15071R
IC HD74HC153FP
IC1507
CK25321R
IC NJM2060M
IC1508
CK25321R
IC NJM2060M
IC1509
CK25321R
IC NJM2060M
IC1510
CK25321R
IC NJM2060M
IC1512
CK04701R
IC BU4066BCF-E2
IC1513
CK04701R
IC BU4066BCF-E2
IC1701
CK25731U
IC M38197MAA630FP
IC1702
DD10161
DISPLAY
IC1703
CJ00252U
IC RPM6938-V4
IC1704
CK19602R
IC RN5VS45AA
IC1761
1352612
IC BA15218F-E2
IC3301
CK31491R
IC BA7660FS-E2
IC3302
CK31491R
IC BA7660FS-E2
LD1701
CH10812R
DIODE SLR325MG3F
LD1702
CH10812R
DIODE SLR325MG3F
LD1703
CH10811R
DIODE SLR325VR3F
LD1704
CH10811R
DIODE SLR325VR3F
LD1802
CH10811R
DIODE SLR325VR3F
Q1306
CA11266R
TRANSISTOR DTC114TKA
Q1307
CA11266R
TRANSISTOR DTC114TKA
Q1308
CA11266R
TRANSISTOR DTC114TKA
Q1309
CA11266R
TRANSISTOR DTC114TKA
Q1310
CA11266R
TRANSISTOR DTC114TKA
Q1311
CA11266R
TRANSISTOR DTC114TKA
Q1701
CA11251R
TRANSISTOR DTA124EKA
Q1702
CA11251R
TRANSISTOR DTA124EKA
Q1703
CA11251R
TRANSISTOR DTA124EKA
Q1704
CA11251R
TRANSISTOR DTA124EKA
Q3503
CA11266R
TRANSISTOR DTC114TKA
Q3504
CA11266R
TRANSISTOR DTC114TKA
Q3510
CA11266R
TRANSISTOR DTC114TKA
Q3511
CA11251R
TRANSISTOR DTA124EKA
Q3512
CA11266R
TRANSISTOR DTC114TKA
ZD1301 CC10431R
DIODE MA3020
ZD1303 CC10431R
DIODE MA3020
ZD1304 CC10431R
DIODE MA3020
ZD1306 CC10431R
DIODE MA3020
ZD1351 CC10431R
DIODE MA3020
ZD1370 CC10431R
DIODE MA3020
ZD1372 CC10431R
DIODE MA3020
ZD1701 5339251
DIODE HZS2-C3
ZD1702 5339262
DIODE HZS6-C2
ZD3501 CC10431R
DIODE MA3020
ZD3502 CC10431R
DIODE MA3020
