1. MECHANICAL PARTS LIST
CHAPTER 4
MECHINISM SECTION
101 PM10791 COVER,TOP
102 QD19081 COVER,SIDE(R)
103 QD19741 COVER,SIDE(L)
104 UH10863 COVER,BOTTOM
105 PM10722 PLATE,REAR
106 QD19141 COVER,TRAY
107 QD19591 COVER,TRAY(S)
108 HA10454 POWER UNIT
109 EV10812 CORD,AC
110 EF11791 CONNECTOR
111 QD18972 COVER,FRONT
112 PC16711 KNOB,VOLUME
113 UQ23301 GD-2501WHA
114 TS15291 CD-R(RA1W02AJ)
115 KK10323 RUBBER BELT
901 8699408 SCREW
903 MK12042 SCREW
904 MK12041 3X6 BT BIND SCREW
905 MK12031 SCREW (DT3X8)
906 MK12032 BT BIND SCREW-3MMDX25MM
907 8691408 SCREW(3X33BT)
908 8691306 SCREW (2.6X6)
909 8741406 SCREW (3X6)
ACCESSORIES
802 HL11251 REMOTE HAND SET
803 EW12143 CORD,3PIN
FLHP,IF,JAK BOARD
CAPACITORS
C1301 0800315 ELECTROLYTIC 47UF 6.3V
C1302 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1304 0800307 CERAMIC CAPACITOR 33UF+-20% 10V
C1305 0209903 CERAMIC CHIP 470PF+-5% 50V
C1306 0800315 ELECTROLYTIC 47UF 6.3V
C1307 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1309 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1310 0893018 CERAMIC CHIP 0.022UF+-10% 25V
C1312 0893031 CERAMIC CHIP 1000PF+-10% 50V
C1313 0893031 CERAMIC CHIP 1000PF+-10% 50V
C1314 0893031 CERAMIC CHIP 1000PF+-10% 50V
C1316 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1317 0893033 CERAMIC CHIP 1500PF+-10% 50V
C1318 0893033 CERAMIC CHIP 1500PF+-10% 50V
C1319 0893014 CERAMIC CHIP 0.01UF+-10% 25V
C1320 0893014 CERAMIC CHIP 0.01UF+-10% 25V
C1321 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1322 0893014 CERAMIC CHIP 0.01UF+-10% 25V
C1325 0893014 CERAMIC CHIP 0.01UF+-10% 25V
C1330 0800326 ELECTROLYTIC 100UF 16V
C1331 0893008 CERAMIC CHIP 0.1UF +-10% 16V
C1332 0893018 CERAMIC CHIP 0.022UF+-10% 25V
C1333 0800326 ELECTROLYTIC 100UF 16V
C1334 0800315 ELECTROLYTIC 47UF 6.3V
C1335 0209848 CERAMIC DISC 150PF+-5% 50V
C1338 0209880 CERAMIC CHIP 10PF+-0.5% 50V
C1362 0800326 ELECTROLYTIC 100UF 16V
C1374 AJ10267R CERAMIC CAPACITOR 10000PF+-10% 50V
C1557 AA00698R CERAMIC CHIP 2.2UF+-10% 16V
C1558 AA00698R CERAMIC CHIP 2.2UF+-10% 16V
C1559 0893042 CERAMIC CHIP 6800PF+-10% 50V
C1560 0893042 CERAMIC CHIP 6800PF+-10% 50V
C1561 0893036 CERAMIC CHIP 0.0027UF+-10% 50V
C1562 0893036 CERAMIC CHIP 0.0027UF+-10% 50V
C1563 0209906 CERAMIC DISC 820PF+-5% 50V
C1564 0209906 CERAMIC DISC 820PF+-5% 50V
C1565 0800326 ELECTROLYTIC 100UF 16V
C1566 0800326 ELECTROLYTIC 100UF 16V
C1567 0800317 ELECTROLYTIC 47UF 16V
C1568 0800317 ELECTROLYTIC 47UF 16V
C1571 0209903 CERAMIC CHIP 470PF+-5% 50V
C1572 0209903 CERAMIC CHIP 470PF+-5% 50V
C1583 0800299 ELECTROLYTIC 22UF 16V
C1584 0800299 ELECTROLYTIC 22UF 16V
C1585 AA00698R CERAMIC CHIP 2.2UF+-10% 16V
C1586 AA00698R CERAMIC CHIP 2.2UF+-10% 16V
C1589 0893036 CERAMIC CHIP 0.0027UF+-10% 50V
C1590 0893036 CERAMIC CHIP 0.0027UF+-10% 50V
C1591 0893031 CERAMIC CHIP 1000PF+-10% 50V
C1592 0893031 CERAMIC CHIP 1000PF+-10% 50V
C1593 0800326 ELECTROLYTIC 100UF 16V
C1594 0800326 ELECTROLYTIC 100UF 16V
C1595 0893011 CERAMIC CHIP 0.15UF+-10% 16V
C1596 0893011 CERAMIC CHIP 0.15UF+-10% 16V
C1597 0209903 CERAMIC CHIP 470PF+-5% 50V
C1598 0209903 CERAMIC CHIP 470PF+-5% 50V
C1701 0800154 ELECTROLYTIC 330UF 6.3V
C1703 0893004 CERAMIC CHIP 0.047UF+-10% 16V
C1704 0893008 CERAMIC CHIP 0.1UF+-10% 16V
C1705 0800154 ELECTROLYTIC 330UF 6.3V
C1707 0893008 CERAMIC CHIP 0.1UF +-10% 16V
