1 - 7
4. Instructions on Use
(The following are extracts from the instruction manual. )
FRONT
Displays the status and message of this unit
Lights when the input level exceeds
0 dB during dubbing or recording.
Type of disc inserted into the player
Lights when the angle
can be switched
Title, track or chapter being
selected or played back ,
Surround
Playback control
Remaining disc playback time
or recordable time
Type of disc inserted into the recorder
Lights when the track number is
automatically advanced during recording
Double-speed dubbing (x2)
Repeat play
Lights when the stop position
is in memory.
41
47
46
50
54
42
20
19
19
24 45 52
37
/ I
P O W E R /
S T A N D B Y
OPEN/
CLOSE DISPLAY
OPEN/
CLOSE
DUB MODE PHONES LEVEL
• REC LEVEL •
DUB START
ACTIVE ACTIVE
SOURCE FINALIZE UNFINALIZE ERASE SYNC
TRACK
NO.
AUTO/MANUAL
STOP PLAY/PAUSE STOP PLAY/PAUSE REC STANDBY SKIP SKIP
MIN MAX
Headphone jack (PHONES)
Player tray Recorder tray
DUB START button
DUB MODE button
SOURCE button
FINALIZE button
UNFINALIZE button
ERASE button
Recorder OPEN/CLOSE button
SYNC button
POWER/STANDBY button
STANDBY indicator
STOP button
PLAY/PAUSE button
SKIP buttons
STOP button
TRACK NO.,
AUTO/MANUAL button
PLAY/PAUSE button
REC STANDBY
button
SKIP buttons
[ACTIVE] indicator
[ACTIVE] indicator
Player OPEN/CLOSE button
DISPLAY button
Recording level control
buttons (+/-)
Headphone level control knob (LEVEL)
In the case of headphones with L-shape
plug, the plug will not fit into the jack
correctly: Attach a (generally available)
conversion plug to the L-shape plug.
19
19
19
19
37
21
21
53
24
24
26
24
19
29
19
19 19
24
32
34
36
24
19
*
*
FRONT
