This section applies to upgrades within HP Integrity Superdome systems. For information on upgrades from existing HP 9000 Superdome systems to HP
Integrity Superdome systems, please refer to the upgrade section of the HP 9000 Superdome QuickSpec.
Upgrade Availability Upgrade Availability Upgrade Availability Upgrade Availability
Component Component Component Component Availability Availability Availability Availability
Add on Upgrades Add on Upgrades Add on Upgrades Add on Upgrades
Cell Board and CPUs (A6866A and A6924A) Immediate
2-GB Memory Module (4×512 MB) (A5198A) Immediate
4-GB Memory Module (4×1 GB DIMMs) (A6863A)
PCI-X Chassis (A6864A) Immediate
Superdome I/O Expansion Cabinet (A5861A) Immediate
Redundant PDCA (A5800A) Immediate
Model Upgrades Model Upgrades Model Upgrades Model Upgrades
Superdome 16-way to 32-way Immediate
Superdome 32-way to 64-way Immediate
Superdome I/O Expansion Cabinet Immediate
Upgrade Quick Matrix Upgrade Quick Matrix Upgrade Quick Matrix Upgrade Quick Matrix
Model Upgrade Requirements Model Upgrade Requirements Model Upgrade Requirements Model Upgrade Requirements
Model Upgrade Model Upgrade Model Upgrade Model Upgrade Product Number Product Number Product Number Product Number Configuration Detail Required Configuration Detail Required Configuration Detail Required Configuration Detail Required Comments Comments Comments Comments
Superdome 16-way to 32-way A5204A (includes new system
backplane) Serial number
Existing partition
configuration (cell placement,
iCOD, OE license type)
Media requirements (new
DVD, SCSI converter, etc.) TCE Manager and
Deployment Manager
High-level design,
recommended detailed design
Order-entry process through
SBW/Watson Config
(recommended to identify
impact of cell placement,
additional software license,
etc.)
Installation of new backplane
included. For additional add
on components, see table
below.
Superdome 32-way to 64-way A5202A (right cabinet) must be
ordered. A Superdome Service
Solution will be required for the
upgrade. These solutions
(combination of solution level
(Foundation, Proactive, Critical) and
ordering category (1st system,
additional system, additional system
later) are selected in SBW/Watson to
populate the appropriate product
numbers and support. The upgrade
includes the right cabinet and
integrated cells, CPUs, memory and
I/O chassis.
NOTE: NOTE: NOTE: NOTE: At least one cell board
(A6866A) with one active processor
(A6924A), one memory module
(A6439A/A6863A), one I/O Card
Cage (A6864A) and one Core I/O
Serial number
Existing partition
configuration (cell placement,
iCOD, OE license type)
Media requirements (new
DVD, SCSI converter, etc.) TCE Manager and
Deployment Manager
High-level design, detailed
design
Order-entry process through
SBW/Watson Config and
Convert to Order required to
place cells in correct slot
locations
Installation included. For
additional add on
components, see table below.
QuickSpecs HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way,
and 64-way and 64-way and 64-way and 64-way
Upgrades
DA - 11717 Worldwide — Version 1 — June 30, 2003 Page 27
