24
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
REPAIR PARTS SNOW THROWER - MODEL NUMBER 924SB (96193005500)
AUGER HOUSING / IMPELLER ASSEMBLY
1
1
2
2
3
3
4
4
5
5
01.07.029-A
1 532 43 27-65 PLASTIC RETAINER
2 532 42 77-62 AUGER BALL BEARING
3 532 17 95-82 SCREW 5/16−18 X 1.00
4 874 78 04-26 SCREW 1/4−20 X .625
5 873 80 04-00 NUT 1/4-20
1
1
2
2
3
3
01.11.002-B
1 532 43 57-85 SKID PLATE
2 872 27 05-06 CARRIAGE BOLT 5/16−18 X .750
3 532 75 11-53 NUT 5/16−18
