Hearth and Home Technologies 3100-I - Manual (Page 3)

Page 3 September 1, 2008
3100-I ACT WOOD INSERT R
250-638D
SAFETY & OVERVIEW OF APPLIANCE
Serial Number /Listing Label Location ------------------
Dimensions ----------------------------------------------------- 4
Minimum Clearances to Combustibles ------------------ 5
Installation Recommendations ---------------------------- 6
Listings & Safety Notices ----------------------------------- 6
Chimney Height & Draft and 2-10-3 Rule -------------- 6
Installation Recommendations ---------------------------- 6
General Installation Procedures -------------------------- 7
Alternate Floor Protection Worksheet ------------------- 7
Chimney Requirements ------------------------------------- 8
Ovalizing Round Stainless Steel Liners ---------------- 8
INSTALLATION OPTIONS
Masonry Fireplace -------------------------------------------- 9
Metal Heat Exchanger Masonry -------------------------- 9
Zero Clearance Factory Built Fireplace ----------------- 10
Canadian Masonry & Heat Circulating ------------------ 11
Leveling Bolts -------------------------------------------------- 11
Securing Liner to Chimney Ring -------------------------- 11
PARTS & ACCESSORY INSTALLATION
Panel & Trim Set ---------------------------------------------- 12
Door Handle Assembly -------------------------------------- 12
Fan (Blower) Assembly ------------------------------------- 13
Fan Speed Adjustment -------------------------------------- 13
Zero Clearance Adjustable Trim Support --------------- 14
OPERATION OVERVIEW
Wood Selection & Storing ---------------------------------- 15
Overfiring ------------------------------------------------------- 15
Building A Fire ------------------------------------------------- 15
Operating Tips ------------------------------------------------- 16
Burn Rates ----------------------------------------------------- 16
Opacity ---------------------------------------------------------- 16
Fan Operating Instructions --------------------------------- 16
Ash Removal -------------------------------------------------- 16
Air Quality ------------------------------------------------------ 17
Air Controls, Primary and Start-up ----------------------- 17
TABLE OF CONTENTS
MAINTENANCE
Plated Surfaces ----------------------------------------------- 18
Glass Cleaning & Replacement --------------------------- 18
Creosote Formation & Removal -------------------------- 18
Chimney --------------------------------------------------------- 18
Brick Replacement ------------------------------------------- 19
Baffle Removal ------------------------------------------------ 19
Exploded Views ----------------------------------------------- 0
PARTS & ACCESSORIES LISTS ------------------------ 21-22
Service & Maintenance Log -------------------------------- 23-24
Homeowner’s Notes ----------------------------------------- 5
Warranty Policy ------------------------------------------------ 26-27
Contact Information ------------------------------------------ 28
