3100-I ACT WOOD INSERT
Page 0 September 1, 2008
R
250-6381D
EXPLODED VIEW
1
9
10
11
2
4
3
8
6
7
5
Item Description Item Description
1 Trim Ring, Louver 7 Screen, Left/Right (interchange-
able)
Manifold Tubes, Back (3) 8 Speed Control
3 Manifold Tube, Front (1) 9 Baffle, Fiberboard
4 Spring Handle, 1/4” (2) 10 Blanket, Ceramic
5 Blower Assembly 11 Brick, Set
6 Louver Assembly
