Page 21 September 1, 2008
3100-I ACT WOOD INSERT R
250-638D
Item
#
Part Description
Alphabetical Order
SKU
9 Baffle, Fiberboard 831-1800
10 Blanket, Ceramic, 1 inch thick 832-3401
Blower Assembly, with Wire Harness 831-1101
Blower Cord with Speed Control & Wire Harness 832-1400
5 Blower Assembly 831-1101
Blower Replacement (1) 832-3190
11 Brick Set 831-1830
Brick with Hole SRV436-0380
Brick, Single, Uncut 832-0550
Brick, Uncut, Set of 6 832-3040
Component Pack (Includes Owner’s Manual, Touch-Up Paint, Leveling Bolts, EPA & Sales Efficiency Card, Warranty
Card, Consumer View Card, Permanent Label ( If Fireplace Altered”)
436-5300
17 Cam Latch (Door Handle) 430-1141
Door Assembly, Black 832-1092
Door Assembly, Gold Trim 832-1912
Door Assembly, Nickel Trim DR-31/43NL
10 Door Handle 430-1131
Door Handle Assembly 832-0540
Gasket (Rope), Door 3/4” x 84” 832-1680
Gasket (Tape), Glass 832-0460
16 Glass Assembly 7000-012
21 Glass Frame, Set 832-0350
22 Hinge Pins, Gold (2) 832-0250
22 Hinge Pins, Nickel (2) 430-5320
19 Key, Cam Latch (Door Handle) 430-1151
Leveling Bolts 220-0080
Manifold Clip with Screws (4) 832-0661
2 & 3 Manifold Tubes, Set (4) 831-1810
18 Nut, Locking (Door Handle) 226-0100
Rivnut Repair Kit REPAIR-RIVNUT
6 Screen Assembly, Louver, Gold 831-0870
6 Screen Assembly, Louver, Nickel LVR-31-NL
7 Screen Assembly, Black 831-0920
20 Screws, Glass Frame (10) 832-0860
8 Speed Control Only 842-0370
4 Spring Handle, Air Control, 1/4”, Gold (2) 832-0630
4 Spring Handle, Air Control, 1/4, Nickel 250-8340
13 Spring Handle, Door, 1/2”, Gold 832-0620
13 Spring Handle, Door, 1/2”, Nickel 250-8330
15 Trim Ring for Door, Gold 430-2682
15 Trim Ring for Door, Nickel 430-5340
SERVICE PARTS
