NOTE: If there is only one waypoint in a route, the Next Waypoint and the End Waypoint info boxes will display
the same information, both for that next waypoint..
XTE (Cross Track Error): Distance of Boat from Route
1
Compass
2
Cartography
3
Course Projection Line
4
Next Waypoint
5
Boat Icon
6
Track
7
Map Scale
8
ETA: Estimated time of arrival
14
DTG: Distance to Go to Waypoint
15
Speed: the measurement of the boat’s progress across
a given distance; the speed measurement provided by GPS.
16
17
Chart Instrument View (Navigating)
9
10
11
12
13
14
15
16
1
17
18
19
20
21
2
1
3
Bearing: Direction to Destination Waypoint
measured in degrees from North
9
Course: the current direction the boat is traveling
measured in degrees from North.
10
Time
11
Latitude and Longitude Position of Boat
12
END: Last waypoint in the route
13
5
5
8
Timer: Elapsed time with
Speed accessory or GPS Receiver.
Distance: Distance traveled with
Speed accessory or GPS Receiver.
Average Speed: Average speed reading
with Speed accessory or GPS Receiver.
TRIPL
OG
NEXT: Next Waypoint in the Route
18
TTG: Time to Go to Waypoint
19
DTG: Distance to Go to Waypoint
20
Voltage
21
4
6
7
