INSTALL INSTRUCTIONS for KK-F-VAK
FORD VAN REAR AIR VENT ADAPTER KIT
TOOLS REQUIRED:
Ratcheting wrench
Standard & Metric Socket Set
Screwdriver set
Wire cutters
HARDWARE:
QTY DESCRIPTION
PART #
1 Heat/Cool Adaptor box assembly KKM01152
1 Ford Rear Air Hose Adapter KKM01153
1
Ford Heat/Cool Box mounting channel KKM99071
10 Hose Clamps 3” GSM20045
2 4” Hose Clamps GSM20042
4’ 4” Diameter Hose GSM40100
4 Vent cover w/ hose adapter assembly
KKM0403-001
1 2 ½” “Y” Duct Connector PRM97483
1 2 ½” Air Duct Hose 8 foot length PRM97475
1 2 ½” Air Duct Hose 7 foot length PRM97475
1 2 ½” Air Duct Hose 6 foot length PRM97475
2 2 ½” Air Duct Hose 4 foot length PRM97475
20 #10 X ¾” Sheet Metal Screws
GSM33195
20 #10 Star Washers GSM31034
20 #10 x ¾” Flat Head Sheet Metal Screws GSM34151
20 15” Wire Tie GSM20036
Always
!
¾ Read all instructions before installing any Havis-Shields Equipment Corp products.
¾ Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾ Use hardware provided with install kit
¾ For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html , email [email protected] or call
1-800-524-9900.
