Operation
Port Switching
All port switches begin with pressing the Scroll Lock key twice. Table 3-1 and Table 3-2
describe the actions that each key combination performs.
NOTE: If using the Scroll Lock key conflicts with other programs running on the computer, the Ctrl
key can be used instead. To use the Ctrl key, refer to “Alternate Port Switching Keys” in this chapter.
Table 3-1: Cycling Through Ports
Hotkey Action
Scroll Lock
Scroll Lock
Enter Switches KVM focus, audio focus, and USB peripherals from the port
that currently has the KVM focus to the next port on the installation.
The KVM focus, audio focus, and USB peripherals all go to this port
even if they were initially on different ports.
K Enter Switches KVM focus to the next port on the installation. The USB
peripherals and audio focus remain unchanged.
U Enter Switches USB peripherals to the next port on the installation. The KVM
focus and audio focus remain unchanged.
S Enter Switches audio focus to the next port on the installation. The KVM
focus and USB peripherals remain unchanged.
Table 3-2: Selecting a Port
Hotkey Action
Scroll Lock
Scroll Lock
n Enter Switches KVM focus, audio focus, and USB peripherals to port n
n K Enter Switches KVM focus to port n
n U Enter Switches USB peripherals to port n
n S Enter Switches audio focus to port n
n K U Enter Switches KVM focus and USB peripherals to port n
n K S Enter Switches KVM focus and audio focus to port n
n S U Enter Switches audio focus and USB peripherals to port n
n K S U Enter Switches KVM focus, audio focus, and USB peripherals to port n
3-2 HP 1x4 USB/PS2 KVM Switch User Guide
