Protocol VLAN Configuration Screen
3-26
VLAN Configuration
Protocol Type
(Selectable)
Select one of the following protocol types:
IP – pertains to all IP associated Ether Types (i.e., 0x0x0800, 0x0806,
and, 0x8035).
IPX – pertains to all IPX associated Ether Types (i.e., 0x8137,
0x8138, and special cases, 0x0100 [LLC Type 1 Encapsulation] and
0x0101 [LLC Type 2 Encapsulation]).
Appletalk – pertains to all Appletalk associated Ether Types (i.e.,
0x809B and 0x80F3).
Netbios – pertains to all Netbios associated Ether Types (i.e. 0x0102).
Banyan Vines – pertains to all Banyan Vines associated Ether Types
(i.e., 0x0103 and 0x0BAD).
DECNET – pertains to all DECNET associated Ether Types.
CUSTOM – when this field is chosen, Ether Type “0x0” displays so
the user can input a particular Ether Type.
NOTE: Any Ether type selected or entered in the Ether type field and
saved will become part of the selection in the protocol field.
For details, refer to
Feature Status
(Toggle)
Enables or disables the entries. The entries can be made but are not
affective until this field is set to ENABLED. The choices for this field
are:
ENABLED
DISABLED
Action
(Toggle)
Used to add or delete an entry (Priority) and its protocol. This field
toggles between [ADD/MODIFY] and [DELETE].
ADD/MODIFY– adds the new Priority and Protocol Type entries (for
example, Priority [0] and Protocol Type [Banyan Vines]).
DELETE – deletes an existing entry with the associated priority (for
example, Priority [0] and Protocol Type [Banyan Vines]).
Table 3-6
Protocol VLAN Configuration Screen Field Definitions (Continued)
Use this field …
To …
