Protocol VLAN Configuration Screen
3-24 VLAN Configuration
3.8 PROTOCOL VLAN CONFIGURATION SCREEN
When to Use
To assign a protocol to a VLAN ID on one or more ports on the switch. This enables the switch to
add a particular VLAN identifier with the specified protocol to each frame that arrives on a
configured port.þ Other switches receiving the frame will classify the frame according to the
VLAN identifier within the frame. Entries may also be deleted or modified.
When the frame is transmitted, it is sent to the ports associated with the VLAN ID as established
using the Protocol Port Configuration screen.
How to Access
Use the arrow keys to highlight the PROTOCOL VLAN CONFIGURATION menu item on the
802.1Q VLAN Configuration Menu screen and press ENTER. The Protocol VLAN Configuration
screen displays.
Screen Example
Figure 3-9 Protocol VLAN Configuration Screen
Firmware Revision: XX.XX.XX
Protocol VLAN Configuration
25991_23
Module Type: xxxx-xx
Slot Number: xx
BOOTPROM Revision: XX.XX.XX
2E253-49R LOCAL MANAGEMENT
RETURN EXIT
Configured Ports
Protocol Type: [ CUSTOM ] Ether type: 0x0800
[ ADD/MODIFY ]
SAVE
ALL PORTS
USER DEFINED PORT LIST
VLAN ID Protocol Type
0001 0x0800 (IP)
0002 0x0801 (CUSTOM)
VLAN ID: [ 2 ]
Action:
PREVIOUS NEXT
Configure Ports: [ ALL PORTS ]
Feature Status: [ ENABLED ]
