34
Issue: 1.0
5. Specifications
5.1 General Specifications
Pickup Device 1/2.8” Sony Exmor R 2.1 megapixel Color Progressive CMOS sensor
Pixels 1920x1080 with 2.5µx 2.5µ pixel size
Image Area Dimensions 4.8mm x 2.7mm (16:9 aspect ratio; 5.52mm diagonal)
Sensitivity 0.2lux/F=1.6 DSS off color; 0.1lux ICR removed; .001lux DSS @ 64X
[EverFocus recommends not exceeding 4x~8x DSS without careful consideration]
Digital Slow Shutter Programmable Off or 2X~64X; max 8X recommended
S/N Ratio Max. 50dB
Video Format Main Output HDcctv
Resolution Main Output Field select HD1080 or HD720
Video Mode Main Output Field select 1080i60/50; 1080p30/25; 720p60/50/30/25
Main Output Connector BNC-F
Video Format Test Output NTSC/PAL selectable
Analog Video Output Connector BNC-F
Electronic Shutter Auto/Manual selectable
Lens Focal Length &
Angle of View
12X zoom: 5.0mm wide ~ 60mm tele (F2.0~3.0)
Optical view angle ~52.4°(wide) to ~4.64° (tele)
Digital Zoom Up to 10X; optional activation after full 12X optical zoom
Auto Focus Choose Off/manual, full auto or ‘one touch’ (holds focus after initial setting after movement)
Pan and Tilt
Range and Speed
Pan: Speed up to 360°/sec; continuous 360° rotation
Tilt: speed up to 260°/sec; 180° range (+/- 90°); digital auto flip for continuous tracking
Maximum 0.75 seconds present recall time; manual speed proportional to zoom ratio
True Day/Night Control Yes (Auto IR cut filter removal); Manual select always color or always B/W.
Electronic Wide Dynamic Range On/Off selectable
Back Light Compensation On/Off selectable
Auto Gain Control Yes (Level 0~186)
Auto White Balance ATW/Push/Manual/Specific Color or Color Temperature
DNR Off/Low/Mid/High selectable
OSD Menu Yes (controlled via RS-485; optional password protection)
OSD Data Display Select interval and position for optional display of zoom level, camera ID, mode and/or angle
Image Flip Digital auto flip at when camera tilts thought bottom position selectable on/off
Presets Up to 210 positions may be stored; programmable preset speed
Auto Scan Zones Up to 8 auto scan zones
Patterns Up to 6 patterns may be memorized and stored
Tours Up to 8 tours (consisting of presets, patterns and scans)
Privacy Zones Up to 8 ‘smart’ zones that automatically adjust relative position as the camera moves
