20
Issue: 1.0
3.4.4 Image Setup
This menu is for changing displayed image settings.
- Enter into {Main Menu}
- Select {Display} and move to {Image Setup} using joystick [ ▶ ].
- Using joystick [ ▶ ], Normal image, Horizontal image, Vertical image or H/V image can be selected.
- Press [Open] button or use joystick to save settings.
- Press [Close] button or use joystick to return to previous menu (Back).
3.4.5 MD (Motion Detection)
The dome camera can monitor the movement of image, and it sends an alarm message with OSD and Alarm Out
action. The level for sensitivity can be changeable.
NOTE* To stop alarm temporarily (about 10sec), press [ESC] button or [96+preset].
- Set MD for Off/MD using the joystick.
- Set Alarm mode for OSD/Alarm Out/Both using the joystick.
- Press [Open] button or use joystick to save settings.
- Press [Close] button or use joystick to return to previous menu (Back).
3.5 Camera Setup Menu
