EVGA Classified SR-2 - Manual (Page 10)

10
EVGA Classified Super Record (SR-2)
Dual Xeon Motherboard
Motherboard Specifications
 Size
HPTX (High Performance Technology Extended) form factor of 15 inches x
13.6 inches
 Microprocessor support
Intel 1366 Xeon Dual QPI Microprocessor
 Operating systems:
Supports Windows XP 32bit/64bit , Windows Vista 32bit/64bit or
Windows 7 32bit and 64bit (64bit Recommended)
 Contains Intel 5520 and ICH10R chipset
 System Memory support
Supports triple channel DDR3-1600+ (Overclocked). Supports up to 48GBs
DDR3 (ECC or Non ECC memory).
 USB 2.0 Ports
Supports hot plug
Ten USB 2.0 ports (six back panel ports, four onboard USB headers)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 protocol up to 480 Mbps transmission rate
Two USB 3.0 ports (Rear panel)
Backwards compatible USB 2.0 and USB 3.0 support.
Supports up to 4.8Gbps transmission rate
