16
49-2001160 Rev. 0
Installation Instructions
UNPACKING YOUR COOKTOP
CAUTION
'2127/,)7
FROM VENT OPENING OR
%803*/$66
Check to be sure that all packing materials
and tape have been removed. This will include
tape on control knobs (if applicable), adhesive
tape, wire ties, cardboard and protective plastic.
Failure to remove these materials could result
in damage to the appliance once the appliance
has been turned on and surfaces have heated.
INST
ALLA
TION INSTRUCTIONS
Vent Grille
Cleaning Cream
Sheet Metal
Screws (9)
(8-18 x 3/8") Foam Gasket Tape
%ORZHU$VVHPEO\DQG0RXQWLQJ
Nuts (10-32 keps – nuts with lock
washers attached)
%ORZHU
Plenum
Vent
Filter
Ceramic
Cooktop
Cleaner
CAUTION
GLASS IS FRAGILE
DO NOT BUMP EDGE
OF GLASS DURING
INSTALLATION
Sheet Metal
Screws (2)
(10-16 x 1/2”)
+ROG'RZQ
%UDFNHWV
30" COOKTOP (DIMENSIONS FOR REFERENCE ONLY)
Unit shown fully assembled.
Unit must be vented to the outside!
20 1 »
2
”
22”
28 3 »
4 ”
2 1 »
2 ”
(2 9 »
16 ” SS)
21 7 »
8
”
(21 15 »
16 ” SS)
29 3 »
4
”
(29 13 »
16
” SS)
